Spring Security 验证、授权流程源码级详解

前言

• spring boot 版本: 2.7.3
• 所有中文注释都为作者所加，源代码中并没有
• 本文引用spring security官网的一些图片和介绍

spring security 基本原理

spring security 基于Servlet，通过Filter组成的FilterChain来过滤请求。
强烈建议先看spring security官网的介绍，这对你理解spring security 有很大的帮助。
这里我先介绍一些关键类或接口，强烈建议先看spring security官网的介绍。

• SecurityContextHolder
  • Spring Security 身份验证模型的核心
  • 它包含SecurityContext
• SecurityContext
  • 从SecurityContextHolder中获取，SecurityContext中包含Authentication
• Authentication
  • 用户未验证时，用于提供身份验证凭据（一般是username和password）
  • 认证成功时，提供当前经过身份验证的用户
  • 包含的属性
    • principal 未验证时是通常是username，验证后通常是UserDetails
    • credentials 通常是password。在许多情况下，这将在用户通过身份验证后被清除，以确保它不被泄露。
    • authorities GrantedAuthority的集合，一般是角色
• GrantedAuthority
  • GrantedAuthority是授予用户的高级权限，一般是角色,如”ROLE_USER”、”ROLE_ADMIN”。
  • GrantedAuthority 可以从Authentication.getAuthorities()方法中得到。这个方法提供了一个GrantedAuthority的Collection对象。
• AuthenticationManager
  • AuthenticationManager是定义 Spring Security 的过滤器如何执行身份验证的 API 。
  • AuthenticationManager接口默认的实现是ProviderManager
• ProviderManager
  • ProviderManager是最常用的AuthenticationManager的实现类。ProviderManager管理着一列AuthenticationProvider。
  • 每个AuthenticationProvider都有机会表明身份验证应该成功、失败，或者表明它不能做出决定并允许下游AuthenticationProvider做出决定。如果配置的AuthenticationProvider都不能进行身份验证，则身份验证将失败，并抛出带有ProviderNotFoundException一个特殊AuthenticationException值，表明ProviderManager未配置为支持Authentication传递给它的类型。
• AuthenticationProvider
  • 可以将多个AuthenticationProvider注入ProviderManager。每个AuthenticationProvider都可以执行特定类型的身份验证。例如，DaoAuthenticationProvider支持基于用户名/密码的身份验证，同时JwtAuthenticationProvider支持对 JWT 令牌进行身份验证。
• AbstractAuthenticationProcessingFilter
  • AbstractAuthenticationProcessingFilter用作Filter验证用户凭据的基础。在认证凭证之前，Spring Security 通常使用AuthenticationEntryPoint。
  • 接下来，AbstractAuthenticationProcessingFilter可以对提交给它的任何身份验证请求进行身份验证。

spring security 如何验证

基础的用户名+密码验证流程

请看spring security 默认的过滤器
spring security 默认的登录使用的是用户名+密码，主要的验证流程就是 抽象类AbstractAuthenticationProcessingFilter和实现类UsernamePasswordAuthenticationFilter这个过滤器。

第一步开启过滤链

1.将Servlet转换了HttpServlet
2.判断该路径是否需要验证
3.尝试验证
4.保存session
5.创建SecurityContext
6.如果失败，开启验证失败处理

AbstractAuthenticationProcessingFilter.class

@Override
public void doFilter(ServletRequest request, ServletResponse response, FilterChain chain)
        throws IOException, ServletException {
    // 转化为http请求
    doFilter((HttpServletRequest) request, (HttpServletResponse) response, chain);
}

private void doFilter(HttpServletRequest request, HttpServletResponse response, FilterChain chain)
        throws IOException, ServletException {
    // 通过请求路径判断请求是否需要验证
    if (!requiresAuthentication(request, response)) {
        chain.doFilter(request, response);
        return;
    }
    try {
        // 尝试验证，具体实现在UsernamePasswordAuthenticationFilter类中
        Authentication authenticationResult = attemptAuthentication(request, response);
        if (authenticationResult == null) {
            // return immediately as subclass has indicated that it hasn't completed
            return;
        }
        // 保存session
        this.sessionStrategy.onAuthentication(authenticationResult, request, response);
        // Authentication success
        if (this.continueChainBeforeSuccessfulAuthentication) {
            chain.doFilter(request, response);
        }
        // 验证成功，保存Authentication，创建SecurityContext，开启验证成功处理
        // 具体实现请看源代码
        successfulAuthentication(request, response, chain, authenticationResult);
    }
    catch (InternalAuthenticationServiceException failed) {
        this.logger.error("An internal error occurred while trying to authenticate the user.", failed);
        // 验证失败，清空securityContext，开启验证失败处理
        // 具体实现请看源代码
        unsuccessfulAuthentication(request, response, failed);
    }
    catch (AuthenticationException ex) {
        // Authentication failed
        // 验证失败，清空securityContext，开启验证失败处理
        // 具体实现请看源代码
        unsuccessfulAuthentication(request, response, ex);
    }
}

UsernamePasswordAuthenticationFilter具体处理过程

1.从代码中可以看出，默认的登录路径为’/login’,请求方式只能为POST。
2.获取username和password
3.创建未验证的Authentication对象，设置Details
4.进行验证

UsernamePasswordAuthenticationFilter.class

public static final String SPRING_SECURITY_FORM_USERNAME_KEY = "username";

public static final String SPRING_SECURITY_FORM_PASSWORD_KEY = "password";

private static final AntPathRequestMatcher DEFAULT_ANT_PATH_REQUEST_MATCHER = new AntPathRequestMatcher("/login",
        "POST");

private String usernameParameter = SPRING_SECURITY_FORM_USERNAME_KEY;

private String passwordParameter = SPRING_SECURITY_FORM_PASSWORD_KEY;

private boolean postOnly = true;

public UsernamePasswordAuthenticationFilter() {
    super(DEFAULT_ANT_PATH_REQUEST_MATCHER);
}

public UsernamePasswordAuthenticationFilter(AuthenticationManager authenticationManager) {
    super(DEFAULT_ANT_PATH_REQUEST_MATCHER, authenticationManager);
}

@Override
public Authentication attemptAuthentication(HttpServletRequest request, HttpServletResponse response)
        throws AuthenticationException {
    if (this.postOnly && !request.getMethod().equals("POST")) {
        throw new AuthenticationServiceException("Authentication method not supported: " + request.getMethod());
    }
    String username = obtainUsername(request);
    username = (username != null) ? username.trim() : "";
    String password = obtainPassword(request);
    password = (password != null) ? password : "";
    // 把username和password分别存入principal和credentials，并设置未验证
    UsernamePasswordAuthenticationToken authRequest = UsernamePasswordAuthenticationToken.unauthenticated(username,
            password);
    // Allow subclasses to set the "details" property
    // spring security 默认的类是WebAuthenticationDetails
    // 该类保存有两个属性remoteAddress（访问地址）和sessionId
    setDetails(request, authRequest);
    // 进行验证，成功就返回填充正确属性的Authentication的对线
    // 如果验证失败，就进入异常处理阶段
    // 具体流程请看下文AuthenticationManager 验证管理流程
    return this.getAuthenticationManager().authenticate(authRequest);
}

AuthenticationManager 验证管理流程

AuthenticationManager接口的实现类为ProviderManager。

1. 遍历AuthenticationProvider，先判断该AuthenticationProvider是否支持提供的Authentication
2. 如果该AuthenticationProvider不支持提供的Authentication，就继续遍历
3. 如果支持验证，则开启验证

ProviderManager.class

@Override
public Authentication authenticate(Authentication authentication) throws AuthenticationException {
    Class<? extends Authentication> toTest = authentication.getClass();
    AuthenticationException lastException = null;
    AuthenticationException parentException = null;
    Authentication result = null;
    Authentication parentResult = null;
    int currentPosition = 0;
    int size = this.providers.size();
    for (AuthenticationProvider provider : getProviders()) {
        // 判断该AuthenticationProvider是否支持验证提供的Authentication
        if (!provider.supports(toTest)) {
            continue;
        }
        if (logger.isTraceEnabled()) {
            logger.trace(LogMessage.format("Authenticating request with %s (%d/%d)",
                    provider.getClass().getSimpleName(), ++currentPosition, size));
        }
        try {
            // 进行验证
            // 请看AbstractUserDetailsAuthenticationProvider类中的authenticate方法(下文中介绍细节)
            result = provider.authenticate(authentication);
            if (result != null) {
                copyDetails(authentication, result);
                break;
            }
        }
        catch (AccountStatusException | InternalAuthenticationServiceException ex) {
            prepareException(ex, authentication);
            // SEC-546: Avoid polling additional providers if auth failure is due to
            // invalid account status
            throw ex;
        }
        catch (AuthenticationException ex) {
            lastException = ex;
        }
    }
    if (result == null && this.parent != null) {
        // Allow the parent to try.
        try {
            parentResult = this.parent.authenticate(authentication);
            result = parentResult;
        }
        catch (ProviderNotFoundException ex) {
            // ignore as we will throw below if no other exception occurred prior to
            // calling parent and the parent
            // may throw ProviderNotFound even though a provider in the child already
            // handled the request
        }
        catch (AuthenticationException ex) {
            parentException = ex;
            lastException = ex;
        }
    }
    if (result != null) {
        if (this.eraseCredentialsAfterAuthentication && (result instanceof CredentialsContainer)) {
            // Authentication is complete. Remove credentials and other secret data
            // from authentication
            ((CredentialsContainer) result).eraseCredentials();
        }
        // If the parent AuthenticationManager was attempted and successful then it
        // will publish an AuthenticationSuccessEvent
        // This check prevents a duplicate AuthenticationSuccessEvent if the parent
        // AuthenticationManager already published it
        if (parentResult == null) {
            this.eventPublisher.publishAuthenticationSuccess(result);
        }

        return result;
    }

    // Parent was null, or didn't authenticate (or throw an exception).
    if (lastException == null) {
        lastException = new ProviderNotFoundException(this.messages.getMessage("ProviderManager.providerNotFound",
                new Object[] { toTest.getName() }, "No AuthenticationProvider found for {0}"));
    }
    // If the parent AuthenticationManager was attempted and failed then it will
    // publish an AbstractAuthenticationFailureEvent
    // This check prevents a duplicate AbstractAuthenticationFailureEvent if the
    // parent AuthenticationManager already published it
    if (parentException == null) {
        prepareException(lastException, authentication);
    }
    throw lastException;
}

AbstractUserDetailsAuthenticationProvider 验证流程

1.获取用户（先从缓存中获取， 如果缓存中没有就从数据库中拿）
2.如果数据库中没有用户，会抛出UsernameNotFoundException
3.拿到用户之后会检查密码是否正确，账号是否锁住，是否过期等等，如果出现问题会抛出异常
4.上述没有问题后，如果是从数据库拿的用户，则会把用户放入缓存
5.创建成功验证，返回Authentication

AbstractUserDetailsAuthenticationProvider.class

@Override
public Authentication authenticate(Authentication authentication) throws AuthenticationException {
    // 判断Authentication 是否是UsernamePasswordAuthenticationToken的实例
    Assert.isInstanceOf(UsernamePasswordAuthenticationToken.class, authentication,
            () -> this.messages.getMessage("AbstractUserDetailsAuthenticationProvider.onlySupports",
                    "Only UsernamePasswordAuthenticationToken is supported"));
    String username = determineUsername(authentication);
    boolean cacheWasUsed = true;
    // 从缓存中获取用户
    UserDetails user = this.userCache.getUserFromCache(username);
    // 缓存中没有用户，需要从数据库中获取用户
    if (user == null) {
        cacheWasUsed = false;
        try {
            // 获取用户，具体实现在实现类DaoAuthenticationProvider中
            // 我们要实现的UserDetailsService的接口中的loadUserByUsername方法，就与这个方法有关
            user = retrieveUser(username, (UsernamePasswordAuthenticationToken) authentication);
        }
        // 用户未找到异常
        catch (UsernameNotFoundException ex) {
            this.logger.debug("Failed to find user '" + username + "'");
            if (!this.hideUserNotFoundExceptions) {
                throw ex;
            }
            throw new BadCredentialsException(this.messages
                    .getMessage("AbstractUserDetailsAuthenticationProvider.badCredentials", "Bad credentials"));
        }
        Assert.notNull(user, "retrieveUser returned null - a violation of the interface contract");
    }
    try {
        // 检查账号是否锁定、是否可用、是否过期
        this.preAuthenticationChecks.check(user);
        // 检查密码是否正确，错误会抛出BadCredentialsException异常
        additionalAuthenticationChecks(user, (UsernamePasswordAuthenticationToken) authentication);
    }
    catch (AuthenticationException ex) {
        // 数据是从数据库中拿到的，有异常直接抛出
        if (!cacheWasUsed) {
            throw ex;
        }
        // 这段是说数据是在缓存中拿到的，出现了异常，现在去数据库再拿一次
        // There was a problem, so try again after checking
        // we're using latest data (i.e. not from the cache)
        cacheWasUsed = false;
        user = retrieveUser(username, (UsernamePasswordAuthenticationToken) authentication);
        this.preAuthenticationChecks.check(user);
        additionalAuthenticationChecks(user, (UsernamePasswordAuthenticationToken) authentication);
    }
    // 检查用户凭证（密码）是否过期，这个主要看你自己在UserDetails怎么设置的
    this.postAuthenticationChecks.check(user);
    // 如果没使用缓存，则把用户存入缓存
    if (!cacheWasUsed) {
        this.userCache.putUserInCache(user);
    }
    Object principalToReturn = user;
    if (this.forcePrincipalAsString) {
        principalToReturn = user.getUsername();
    }
    // 创建成功验证，该类的方法中已经实现基本流程，实现类中增加了，把原始密码加密
    return createSuccessAuthentication(principalToReturn, authentication, user);
}

检索用户的具体流程

1.一般是通过我们实现UserDetailsService接口中的loadUserByUsername方法来检索用户
2.如果没有找到，则抛出UsernameNotFoundException异常
DaoAuthenticationProvider.class

@Override
protected final UserDetails retrieveUser(String username, UsernamePasswordAuthenticationToken authentication)
        throws AuthenticationException {
    prepareTimingAttackProtection();
    try {
        // 这就是我们实现UserDetailsService接口中的loadUserByUsername方法调用的地方
        UserDetails loadedUser = this.getUserDetailsService().loadUserByUsername(username);
        if (loadedUser == null) {
            throw new InternalAuthenticationServiceException(
                    "UserDetailsService returned null, which is an interface contract violation");
        }
        return loadedUser;
    }
    catch (UsernameNotFoundException ex) {
        mitigateAgainstTimingAttack(authentication);
        throw ex;
    }
    catch (InternalAuthenticationServiceException ex) {
        throw ex;
    }
    catch (Exception ex) {
        throw new InternalAuthenticationServiceException(ex.getMessage(), ex);
    }
}

spring security 如何授权

spring security + jwt
